Aluminum Track Hardware Aluminium Track Suit To Frameless Glass Folding Door
Welcome a trial order!
Contact us at any time!
| Model No. | GS3 | Bearing grade | CV2 |
| Application | Suitable for glass partition | Glass clamp cut size(mm) | 111*36 |
| Function | Side folding,each door width is same | Glass clamp material | Aluminium 6063-T5 |
| Max door leaf height(mm) | 3000 | Glass clamp finishes | A) Anodizing matt silver B) Anodizing hairline black C) Customized |
| Max door leaf width(mm) | 1100 | Hinge size(mm) | 111*87.5*3 |
| Max door leaf load(kg) | 100 | Elbow material | Aluminium |
| Glass thickness(mm) | 10-12 | Hinge finish | SSS/black |
| Top track size(mm) | 80*53 | End cap material | stainless steel/Nylon |
| Top track thickness(mm) | 3 | End cap finish | SSS/Silver/Black |
| Top track material | Aluminum 6063-T5 | PVC seal | Optional |
| Top track finish | Anodizing matt silver | Lock | Optional |
| Roler material | Aluminum | Lacth | Optional |
Popular modern design large opening double glazed aluminum insulated folding door
We can sell complete set with glass, or only hardware accessories.
